5kw Hydrogen Fuel Cell Power Generator + 4kw Heater Unit for Home / Small Commerical Use

Basic Info.

Model NO.	CarNeu-5
Solutions	Direct Type
Transport Package	Wooden Case
Specification	5KW Power + 4KW Heat
Trademark	CarNeu
Origin	China
HS Code	8501610000
Production Capacity	300 Sets Per Year

Product Description

Overview
CarNeu-5 is a pure hydrogen fuel cell CHP equipment. Through electrochemical reaction, it reacts hydrogen and air to generate direct current, which is further converted into alternating current through the power electronic system and sent to the power grid for users to use. Waste heat during the equipment working is recovered and supplied to users in the form of hot water. The equipment is composed of a fuel cell module, control module, electrics/electronics module, and thermal management module. The system adopts a low-pressure design that is safe, stable, and has a long service life.
Application Scenarios

Specification

Items	Parameters
Product Name	Hydrogen fuel cell Combined heat and power unit
Product Model No.	CarNeu-5
FC type	LT-PEM
Fuel	99.97% purity H2
Fuel Consumption	0.31kg/h
Electrical Power Output	5kW
Thermal Power OutPut	4kW
Electrical Efficiency	>50%
Total Efficiency	98.50%
Heat Flow	Max. 60ºC/65ºC
Power Connections	380VAC, three-phase or 110V AC, single-phase
Dimensions(L*W*H)	0.8x0.75x1.6m
Weight	about 300kg

Company Profile

Company HonoursCompany Patents

Core Technology Advantages

HuaDe Hydrogen Energy has accumulated rich experience in the field of low-voltage hydrogen fuel cell power generation system, and the technology route is significantly different from the domestic high-pressure fuel cell route for vehicles, which is more in line with the operating requirements of hydrogen fuel cell power stations. Currently, the company has independently mastered the miniaturized natural gas reforming-based hydrogen production technology, low-pressure stationary PEM fuel cell stack technology, and system integration technology. HuaDe Hydrogen is one of the few domestic companies specializing in the research and development of hydrogen cogeneration and distributed energy equipment and realizing the export sales of cogeneration systems.
FAQ1. How long is your product warranty period?The standard warranty period is 12 months. Any damaged parts during the warranty period can be shipped free by express to you and we will offer lifetime technical support and troubleshooting service. The warranty period starts from the normal commissioning at the customer's place. If the commissioning fails due to the customer's installation site or other causes, the warranty period starts 4 weeks after the product arrives at the customer's installation site.We also offer warranty extension service. Pay 10% of the total cost of the equipment every year to extend the one-year warranty. Maximum can extend 10 years.
2. What fields or application scenarios of your fuel cell System?a. H2ES series(natural gas reformed hydrogen fuel cell unit) is suitable for multi-family house buildings, such as apartments, school dormitories, hospital quarters, etc, and also suitable for small commercial buildings, such as hotels, resorts, supermarkets, etc.
b. The CarNeu series( pure hydrogen fuel cell CHP plant) is suitable for - large industrial buildings such as factories, docks, etc. - for big commercial buildings, such as office buildings, shopping malls, etc. - residential community
3. What is the lead time and delivery time for your fuel cell system?Lead time: normally 60 days.Delivery time: shipping by sea takes around 90 days; shipping by railway or truck takes 35-45 days.
4. What are your payment terms?We accept T/T with advanced payment and L/C with advanced payment. If you have special requirements, welcome to contact us.
5. Are you the manufacturer?Yes, we are the manufacturer. Welcome to visit our factory in Suzhou City, Jiangsu Province, China.
